SepaBean™ CorePrep 150 - High Pressure Autosampler
NEW PRODUCT
SepaBean™ CorePrep 150 - High Pressure Autosampler
- Flexible Tube Rack Design: Compatible with 5 mL, 9 mL, and 15 mL sample tubes, offering versatile combinations.
- Independent Injection Module: Operates separately from the collection process, enabling both single injections and repeated stacking without delays.
- Wide Injection Range: Adjustable volumes from 100 μL to 10 mL (± 1 μL) with precise control; injection speed can scale from small to large volumes within 30 seconds.
- High Reproducibility: Residual injection rate below 0.01 % ensures accurate performance even with complex samples.
- Expandable Capacity: Reserved switching port supports larger sample injections, extending the range up to 100 μL - 20 mL.
High Pressure Autosampler Specifications
| Characteristics | Specifications |
|---|---|
| Part Number | UHP-AS01 |
| Description | High Pressure Autosampler |
| Carryover Effect | ≤ 0.01 % |
| 3-Dimensional | XYZ Axis |
| Dimensions (H x W x D) | 400 x 340 x 525 mm |
| Injection Accuracy | ± 2 % |
| Injected Dead Volume | 310 μL |
| Injection Precision | RSD ≤ 1 % |
| Injection Time | The injection cycle time is 32 seconds for a standard 5 mL injection and 50 seconds for a standard 10 mL injection |
| Injection Volume | 100 μL to 5 mL with a standard 5 mL quantitative loop, minimum increment of 1 μL, and can be expanded up to 20 mL |
| Needle Wash | Thorough cleaning of inner and outer walls of the injection needle |
| Sample Rack Options |
10 x 75 mm, 5 mL, 112 wells
13 x 100 mm, 9 mL, 72 wells
16 x 100 mm, 15 mL, 50 wells
30 x 100 mm, 40 mL, 6 wells
|
| Power Supply | 100 - 240 V AC, power 75 W |
| Weight | 35 kg (77 lbs) |
