SepaFlash Column iLOK Series Empty solid load cartridge SD-0000 4g, 12g, 25g, 40g, 60g, 80g, 100g, 120g, 220g, 330g
Ordering Information
iLOK™ Empty Solid Load Cartridges with screw cap, frits, disbursing unit, O-ring and end tips.
Item Number | Column Size | Volume (mL) | Cartridge Length (mm) | Cartridge ID (mm) |
Max. Pressure (psi/bar) |
SD-0000-004 | 4 g | 8 | 115.1 | 12.8 | 200/13.8 |
SD-0000-012 | 12 g | 27 | 137.8 | 21.4 | 200/13.8 |
SD-0000-025 | 25 g | 46 | 188.2 | 21.6 | 200/13.8 |
SD-0000-040 | 40 g | 70 | 188.7 | 26.8 | 200/13.8 |
SD-0000-060 | 60 g | 104 | 173.3 | 36.6 | 200/13.8 |
SD-0000-080 | 80 g | 147 | 263.5 | 31.2 | 200/13.8 |
SD-0000-100 | 100 g | 176 | 146.6 | 60.4 | 150/10.3 |
SD-0000-120 | 120 g | 215 | 277.7 | 36.6 | 200/13.8 |
SD-0000-220 | 220 g | 376 | 218.5 | 60.6 | 150/10.3 |
SD-0000-330 | 330 g | 539 | 271.6 | 60.6 | 150/10.3 |
